| Model | Unit | JEPE 52 - 100 |
JEPE 52 - 170 |
JEPE 65 - 200 |
JEPE 65 - 250 |
JEPE 71 - 350 |
JEPE 90 - 450 |
JEPE 90 - 550 |
JEPE 92 - 700 |
JEPE 110 - 950 |
JEPE 135 - 1500 |
|---|---|---|---|---|---|---|---|---|---|---|---|
| Screw Dia | MM | 52 | 52 | 65 | 65 | 71 | 90 | 90 | 92 | 110 | 135 |
| L/D Ratio | - | 18 : 1 | 25 : 1 | 18 : 1 | 22 : 1 | 28 : 1 | 22 : 1 | 25 : 1 | 28 : 1 | 28 : 1 | 28 : 1 |
| Main Motor | KW | 11.25 | 15 | 22.5 | 22.5 | 30 | 45 | 60 | 75 | 90 | 160 |
| Output | Kgs/hr | 100 - 110 | 150 - 170 | 180 - 200 | 220 - 250 | 300 - 350 | 400 - 450 | 500 - 550 | 650 - 700 | 850 - 950 | 1300 - 1500 |
| Pipe Range (Single Die Head) |
MM | 20 - 110 | 20 - 200 | 20 - 200 | 63 - 250 | 110 - 315 | 110 - 400 | 100 - 400 | 160 - 400 | 160 - 400 | 250 - 630 |
| Pipe Range (Twin Die Head) |
MM | 19 - 50 | 19 - 50 | 19 - 50 | 20 - 110 | 20 - 110 | 20 - 110 | 63 - 200 | 63 - 200 | 90 - 200 | 110 - 250 |
